Features

Four Independent Timer Settings for Gas Injection Channels, each with 8 nozzles, allows each channel to be controlled separately,allowing different volumes and solvents to be evaporated simultaneously

Two Step Control of Gas/Air Injection pressure/time, allows both initial and running pressure to be altered on a time base. This allows a gradual change of pressure to prevent “bumping” of the sample on start up

Semi-helical Gas/Air flow via specially designed nozzles, generates a large sample surface area, to maximise the rate of evaporation

Temperature control of the water bath from ambient to 99°C

Status monitoring incorporating “traffic light” indication for heater, ventilation/extract fan and door closure. When all is OK the light is yellow, if there is malfunction or set is incorrect the corresponding light is red

Blue back-lighting to the sample chamber gives excellent definition for viewing the samples via either front or side windows. The light is on/off controlled by a separate switch on the back

Rear mounted extract/ventilation fan for rapid exhaust of gas/vapours (connection to duct & exhaust via fume hood)

Tempered Glass panels to chamber front, sides and top lid

Drain valve + hose for easy replacement of bath water

Diverse range of sample racks catering for various sample containers
