Dispersing aggregate/Model
|
PT-DA 1205/2EC
|
PT-DA 1207/2EC
|
PT-DA 1212/2EC
|
|
Description
|
suirable for smallestamounts andEppendorf tubes
|
suitable for smallammounts and test tubes
|
suitable for smalland larger amounts
|
|
Shaft length
|
100 mm
|
105 mm
|
105 mm
|
|
Stator-Ø
|
5.5 mm
|
7.5 mm
|
12 mm
|
|
Rator-Ø
|
3 mm
|
5 mm
|
9 mm
|
|
Tip speed (max.)
|
3.5 m/s
|
6 m/s
|
11 m/s
|
|
Working volume
|
approx. 0.1-5 ml
|
approx. 0.3-10 ml
|
approx. 2-250 ml
|
|
Recommended dispersing vessel
|
KINEMATICA dispersing vessels from GS 15 up- wards or a vessel with min. 6 mm inside diameter
|
KINEMATICA dispersing vessels from GS 15 up- wards or a vessel with min. 8 mm inside diameter
|
KINEMATICA dispersing vessels from GS 15 up- wards or a vessel with min. 15 mm inside diameter
|
|
Applications
|
• Dispersing smallest amounts of plant, human or animal tissues• Dissolving of solids• Extractions
|
• Dispersing of cellsand tissues in small amounts of liquid• Dissolving of solids• Extractions
|
• Dispersing of plant, human or animal tissues, resins, pigments• Extractions• Producing of suspen- sions/emulsions
|
|
Order Code
|
11030005
|
11030020
|
11030040
|
|
Drive unit/Model
|
Order Code
|
|
PT 1200 B Quick battery charger 230 V Quick battery charger 115 V
|
1101002011010021
|
|
PT 1200 C Europe 230 V, 50/60 Hz Switzerland 230 V, 50/60 Hz Others 115 V, 50/60 Hz
|
110100101101001111010012
|
|
PT 1200 CL 230 V, 50/60 Hz 115 V, 50/60 Hz
|
1101001511010016
|
|
Accessories
|
|
APC 1200 Accessory package with base station and stand incl, carrying case
|
11040005
|
|
GS 15 Dispersing vessel for 25 ml
|
11050010
|
|
GS 25 Dispersing vessel for 90 ml
|
11050011
|
|
GS 40 Dispersing vessel for 300 ml
|
11050012
|
