제품사양
Number of positions
10
Maximum controlled heating cooling rate
5°Cmin
Cell cavity diameter
25.5 mm
Maximum controlled heating cooling ramp rate
0.1°Cmin to 5°Cmin in 0.1°Cmin steps
Glass vessel fill level
2 - 25 ml
Stir speed range
350 - 1200 rpm
Temperature range
- 30°C to + 150°C
Viscosity capacity
Glycerine at 25°C
Temperature difference between any two positions
180°C
Recommended stir bars
12 4.5 mm (cylindrical) or 10 6 mm (oval)
Temperature overshoot
0.1°C (maximum)
Ordering Information
제품코드
PS200000
Integrity 10 with 10 individually controlled cells, 230V
PS200000X1
Integrity 10 with 10 individually controlled cells, 110V
PS200000X6
Integrity 10 with 10 individually controlled cells, 230V, EU Plug
ATS10075
Glass tubes 24 150 mm, 22 thread pack of 10
AZS4206
Stirrer bars 10 6 mm, pack of 10
AZS4235
Stirrer bars 12 4, 5 mm, pack of 10
ATS10001
Multi-Temp 10 module
ATS10027
Thermocouple probe, pack of 6
ATS11005
Integrity software
ATS10360/1
Non Intrusive IR sensor, pack of 1
ATS10230
Small Intrusive IR probe in stainless steel PID-NIR5-BNSD, pack of 1
ATS10230H
IR probe in Hastelloy
ATS10395
Large Intrusive IR and NIR probe
ATS10232E
Multi IR box
