모델명
|
LICO 690
|
LICO 620
|
|
Beam Height
|
10 mm
|
10 mm
|
|
Color Scales
|
Acid Wash;ADMI;ASTM D
1500;Chinese Pharma;DAB
1996;EBC;Gardner;Hazen;Hess
Ives;ICUMSA;Iod;Klett;Saybolt;
USP24 ;Yellowness Index;AOCS y/r
|
Iod;Gardner;
Hazen;Saybolt;ASTM D 1500
|
|
Cuvette compatibility
|
10 mm Rectangular cuvette
50 mm Rectangular cuvette
11 mm Round cuvette
|
50 mm Rectangular cuvette
10 mm Rectangular cuvette
11 mm Round cuvette
|
|
Data storage (데이터 저장)
|
3000 color readings
20 time scans
20 wavelength scans
1000 photometric values
100 color references
|
400 color readings
|
|
Dimensions (H x W x D)
|
151 mm x 350 mm x 255 mm
151 mm x 350 mm x 255 mm
|
151 mm x 350 mm x 255 mm
|
|
Display
|
TFT WVGA Color Graphic Touch
Screen 800 pixel - 480 pixel
|
TFT WVGA Color
Graphic Touch Screen
800 pixel - 480 pixel
|
|
Display size
|
7 inch
|
7 inch
|
|
Display type
|
|
Color Graphic
|
|
Includes
|
cell adapter, dust cover, power supply,
user manu
|
cell adapter, dust cover,
power supply, user manual
|
|
Interface
|
2x USB Typ A, 1x USB Typ B,
1x Ethernet
|
2x USB Typ A, 1x USB Typ B, 1x Ethernet
|
|
Manual languages
|
English, French, German, Italian
|
English, French, German, Italian
|
|
Max. Storage Humidity
|
80%
|
80%
|
|
Max. operating humidity
|
80%
|
80%
|
|
Operating Temperature Range
|
10 to 40 °C
|
10 to 40 °C
|
|
Optical path length
|
10 - 50 mm
|
10 mm - 50 mm
|
|
Optical system
|
0 ° / 180 ° rectilinear
|
0 ° / 180 ° rectilinear
|
|
Photometric accuracy
|
0.005 Abs at 0 to 0.5 Abs
1 % at 0.5 to 2.0 Abs
|
0.005 Abs at 0 to 0.5 Abs
1 % at 0.5 to 2.0 Abs
|
|
Photometric linearity
|
< 0.5 % to 2 Abs with neutral
glass at 546 nm 1 %
with neutral glass at 546 nm
|
< 0.5 % to 2 Abs 1 % with neutral glass at 546 nm
|
|
Photometric measuring range
|
± 3.0 Abs
(wavelength range 340-900 nm)
|
± 3.0 Abs
(wavelength range 340-900 nm)
|
|
Power Requirements (Hz)
|
50/60 Hz
|
50/60 Hz
|
|
Power Requirements (Voltage)
|
110 - 240 V AC
|
110 - 240 V AC
|
|
Power supply
|
110 V - 240 V
|
110 V - 240 V
|
|
Repeatability
|
0.1 E*
|
|
|
Reproducibility
|
± 0.2 % transmission
|
± 0.2 % transmission
|
|
Safety checks
|
CE
|
CE
|
|
Scanning speed
|
8 nm/s (in steps of 1 nm)
|
|
|
Source lamp
|
Tungsten Halogen Lamp
|
Tungsten Halogen Lamp
|
|
Spectral Bandwidth
|
5 nm
|
5 nm
|
|
Standard light type (표준광 형태)
|
AC;D65
|
AC;D65
|
|
Standard Observer
|
2°;10°
|
2°;10°
|
|
Storage conditions
|
-40 °C to 60 °C
|
-40 °C to 60 °C
|
|
User interface
|
English, French, German, Italian,
Spanish, Czech, Dutch, Greek, Polish,
Slovene, Slovake, Russian, Turkish,
Chinese, Japanese, Korean
|
English, French, German, Italian, Spanish, Czech, Dutch, Greek, Polish, Slovene, Slovake, Russian, Turkish, Chinese, Japanese, Korean
|
|
Warranty
|
2 years
|
2 years
|
|
Wavelength accuracy
|
± 1.5 nm
(wavelength range 340-900 nm)
|
± 1.5 nm
(wavelength range 380-720 nm)
|
|
Wavelength calibration
|
automatic
|
automatic
|
|
Wavelength range
|
320 nm to 1100 nm
|
to
|
|
Wavelength reproducibility
|
0.1 nm
|
0.1 nm
|
|
Wavelength resolution
|
1 nm
|
|
|
Weight
|
4.2 kg
|
4.2 kg
|
