Important characteristics
- Temperature range: 0 °C to 70 °C - Humidity range: 10 % to 80 % RH - APT.line™ preheating chamber technology - Humidity regulation with capacitative humidity sensor and vapor humidification - Controller with time-segment programming - Tightly-sealed inner door made of tempered safety glass - 2 stainless steel racks - Access port with silicone plug, 30 mm, left - Class 3.1 independent temperature safety device (DIN 12880) with visual and audible
emperature alarm - Computer interface: Ethernet - Door heating
Designation
KBF115-230V
KBF115UL-240V
Option model
Standard
Order number
9020-0267
9020-0268
Performance Data Temperature
Temperature range [°C]
0…70
Temperature uniformity at 40 °C [± K]
0.2
Temperature fluctuation [± K]
0.1
Max. heat compensation at 40 °C [W]
200
Recovery time after 30 seconds door open
at 25 °C and 60 % RH [min]
15
at 40 °C and 75 % RH [min]
8
Performance Data Climate
10…70
Temperature uniformity at 25 °C and 60 % RH [± K]
Temperature uniformity at 40 °C and 75 % RH [± K]
Temperature fluctuation at 25 °C and 60 % RH [± K]
Temperature fluctuation at 40 °C and 75 % RH [± K]
Humidity range [% RH]
10…80
Humidity fluctuation at 25 °C and 60 % RH
≤2 ± % RH
Humidity fluctuation at 40 °C and 75 % RH
Electrical data
Rated Voltage [V]
200…230
200…240
Power frequency [Hz]
50/60
Nominal power [kW]
2
Phase (Nominal voltage)
1~
Unit fuse [A]
16
Measures
Interior volume [L]
102
Net weight of the unit (empty) [kg]
129
Load per rack [kg]
30
Measures - Doors
Inner doors
1
Unit doors
Measures - Internal Dimensions
Width [mm]
600
Height [mm]
483
Depth [mm]
351
Measures - Outer dimensions
Width net [mm]
880
Height net [mm]
1050
Depth net [mm]
650
Wall clearance back [mm]
100
Wall clearance sidewise [mm]
Environment-specific data
Energy consumption at 40 °C and 75 % RH
470 Wh/h
Sound-pressure level [dB(A)]
52
